Gaggenau - Hob

• Frameless for flush installation
• Frying sensor function
• Large cooking zone for pots up to ø 32 cm
• Twist-Pad control with removable magnetic knob

Cooking zones
• 1 induction cooking zone ø 21 cm (2200 W, with booster 3300 W), automatically switches to ø 26 cm (2600 W, with booster 3400 W) and to ø 32 cm (3300 W, with booster 4600 W)
• 1 induction cooking zone ø 21 cm (2200 W, with booster 3300 W)
• 2 induction cooking zone ø 18 cm (1800 W, with booster 2500 W)
• 1 induction cooking zone ø 15 cm (1400 W, with booster 1800 W)

Handling
• Twist-Pad control with removable magnetic knob
• Cooking zone marking
• Electronic power control in 17 output levels

Features
• Frying sensor function for ø 18 cm and ø 21 cm cooking zones
• Booster function for each cooking zone
• Super booster function for ø 32 cm cooking zone
• Quick boil timer, with individually adjustable boiling time
• Cooking timer for up to 90 minutes
• Short-term timer
• Memory function
• Options menu
• Power management

Safety
• Main switch
• Operation indicator
• Pot detection
• Individual residual heat indicators
• Child lock
• Safety lock

Planning notes
• Operates with magnetic (induction) iron pots and pans only. For an optimal heat
distribution, the use of sandwich bottom cookware is recommended.
The wok pan WP 400 001 cannot be used with this appliance.
• Immersion depth 56 mm
• Appliance must be fixed from underneath
• Cooktop clamping range: 20-40 mm
• Joint width may vary due to dimensional tolerances of the glass ceramic cooktop and the worktop cut-out
• Appliance weight: approx. 18 kg

Connection
• Total connected load 10.8 kW
• Connecting calbe 1.5 m without plug


Smeg - 60cm 'Classic' Steam Oven, Frameless, Anti-Fingerprint, St/Steel

• 45cm reduced height compact oven

6 functions

• Manual steam cooking
• Meat cooking
• Fish cooking
• Vegetable cooking
• Regeneration function
• Defrost

Electronic programmer with:
• Timer
• Delay timer 24h (automatic ignition)
• End of cooking with alarm (automatic switch-off)
• White LED
• Double digital display
• Illuminated symbols indicating Functions

• Recipes already programmed for different types of meat,
fish and vegetables
• Water level light
• Temperature 40-1OO°C regulated in steps of 5 °C
• Electronic temperature control
• Stainless steel interior
• 1.2 litre water tank
• Show—room function (Demo)
• Power ECO mode
• Child lock
• Double glazed door
• Tangential cooling system

Standard Accessories:
• Roasting/grill pan
• Chrome shell
• Grill mesh

• Nominal power: 3.4kW
• Oven capacity: 35 litres

Optional Extras:
• Adjustable kit for 48cm KlT45SX
• Stainless steel spacer PR3845X

Available in the following version:
• Anthracite S45VA


Miele - Steam Oven (Stainless Steel)

Features
• PureLine design
• 60 cm wide, 45 cm tall steam oven
• CleanSteel with stainless steel handle
• 38L capacity with 4 shelf levels
• DirectSensor fascia panel - 4-line text TFT
display with touch controls
• MultiSteam technology
• Approximately 50 Automatic programmes
• Electronic touch controls for program
duration
• Display for choice of language, temperature,
duration, water level, faults and descaling
reminder
• Steam cooking functions with
recommended temperature settings and
special applications
• Minute minder
• Precise electronic temperature control from
40°C - 100°C
• 200 h clock battery backup
• User programmes
• Vapour cooling and venting system
• System lock and safety switch off
• Flush floor heater to reduce condensation
after cooking

Installation requirements
• Permanent connection
1N AC 230 - 240 V / 50Hz
• Rated load 3.4 kW
• Fuse rating 15 A
• Without plug
• Electrical supply required
• Open cabinet

Notes
• Installation in a base unit is not recommended if
there are young children in the home.
• Important: Do not position electrical socket behind
the appliance

Built-in Dimensions
Height (tall unit): 448 - 452 mm
Height (base unit): 460 - 465 mm
Width: 560 - 568 mm
Depth: min. 555 mm
Depth with door open: 89 cm
Net weight: 29.1 kg
* Appliances with glass front
** Appliances with metal front
